Applications
Building materials
Technical data
Anchorage depth hef
hef >/= 30 mm in concrete
hef >/= 40 mm in solid brick
hef >/= 60 mm in perforated brick / aerated concrete
td : drill hole depth >/= hef + 10 mm
Drill hole diameter | d0 | 6 | [mm] |
Screw length | ls | 72 | [mm] |
Drive | T | T30 | |
Head | Ø | 11,5 | [mm] |
This Product was added to our catalogue on 17/01/2017.
